7/13 Pole Towbar Adapter CARGUARD 54945

Tow bar adapter - conversion from 7 to 13 poles, voltage 12/24V, copper connectors for reliable contact, solid design with spring cover, removable and installable connectors, colour-marked wires (left/right index, fog lights, brake lights, reversing lamp, power supply, charging cable), compatible with most cars and trailers, simple wiring without vehicle modifications

Show full description
Not in stock
105,00 Kč 86,78 Kč excl. VAT
CARGUARD  |  SKU: 08750224  |  Barcode: 6425215797608
Log in for VAT-free pricing

Product description

The regulations state that trailers must be equipped with adequate lighting and only then can they join road traffic. With this connector, you can easily connect the lights of the trailer to the car's electrical system.

- Excellent contact
- Copper connectors
- Massive build
- Spring cover
- Removable, installable connectors
- Compatible with most cars and trailers
- Simple connection and assembly

Manufactured in accordance with ISO1724.

Technical parameters:

- Voltage: 12/24V
- Number of poles: 7/13 pcs
- Marking of poles / Cable colors:
1 - yellow - left index
2 - blue - nebulae
3 - white - body
4 - green - right index
5 - brown - right lights
6 - red - brake lights
7 - black - left lights
8 - gray - reversing lamp
9 - brown/blue - power supply
10 - brown/red - charging cable (connected fiber)
11 - free
12 - free
13 - black/white - body
- Cable attachment: Screw
- Color: Black
