Overcurrent Thermal Circuit Breaker ST-1 250VAC/5A or 32VDC/5A
Thermal overcurrent circuit breaker - 250VAC/5A or 32VDC/5A, type ST-1, manual reset, trips after 25–30 s when the rated current is exceeded by 10 %, the trip time shortens as the current increases, faston terminals 6.3 mm, suitable for extension leads, drums, switches as an alternative to fuses
Will be restocked
Expected shipping:
15.10.2026
at our place
Regular price
14,00 Kč
11,57 Kč
excl. VAT
Unit price
/
Unavailable
HADEX | SKU:
04291053
Product description
Overcurrent Thermal Circuit Breaker ST-1 250VAC/5A or 32VDC/5A.
Technical parameters:
- thermal breaker with manual reset
- switches off after 25-30sec when loaded with rated current increased by 10%
- as the current increases, the shutdown time decreases
- terminals: faston 6.3 mm
- for use in extension leads and drums or switches and switches as an alternative to fuses
Technical parameters:
- thermal breaker with manual reset
- switches off after 25-30sec when loaded with rated current increased by 10%
- as the current increases, the shutdown time decreases
- terminals: faston 6.3 mm
- for use in extension leads and drums or switches and switches as an alternative to fuses
