AG13 SMD button cell battery holder

Looking for a miniature, reliable and space-saving solution for powering small electronic devices? The AG13 3V SMD button cell battery holder is designed specifically for modern low-profile applications where every millimeter of PCB area and height matters. This surface mount battery slot (Patch/SMD) allows stable and secure seating of cells directly on the top layer of the PCB without the need to drill holes.

It finds its application in pocket flashlights, laser pointers, toys, promotional items, miniature audio modules or backup power supplies for microprocessors and real-time clocks (RTC).


Main advantages:

- Space-saving SMD design (Patch Holder): the component is soldered directly to the PCB surface. The bottom side of the board remains completely free for other components.
- Optimized for the AG13 / LR44 series. Due to the nominal voltage of a single battery of $1.5{V}$, this holder is generally designed in wiring to place two cells in series on top of each other, providing a resulting stable voltage of 3 V.
- The rigid metal clips with permanent pressure.
- Compatibility with automatic assembly machines.


Technical specifications:

- SMD Button Battery Patch Holder.
- Rated assembly voltage: 3 V (configuration for 2×1.5 V cells in series)
- Compatible Battery Size: AG13/LR44 (and equivalents such as LR1154, L1154, A76)
- PCB mounting type: SMD/SMT (surface mount PCB)
- Contact material: Phosphor bronze with high quality nickel plated surface (corrosion resistant, perfect solderability)
- Mechanical design: low-profile with side fixing plates and top pressure arm

Reduce the dimensions of your electronics to a minimum and simplify their production. Add it to your cart today!
