Battery charger LTC LXB409 12V 750mAh for batteries max. 20Ah

Lead-acid battery charger - output voltage 14.4V DC, max. charging current 750mA, rated current 700mA, input voltage 230VAC, max. power consumption 11W, suitable for batteries up to 20Ah, LED charging status indication, protection against short-circuit, overload and overvoltage, class II double insulation, MTBF 30 000 hours, operating temperature 0–40°C, cable length 1.5 m, dimensions 77 × 30 × 82 mm, weight 140 g

Show full description
In stock 8 pcs
Expected shipping: 25.09.2026
€7,53
LTC  |  SKU: 06437882  |  Barcode: 5902270713084
Log in for VAT-free pricing

Product description

This charger is used for charging lead-acid batteries with a built-in short-circuit and overload protection.

Properties:

- LED indication of charging status
- Output voltage: 14.4V DC
- Maximum output current: 750 mA
- Rated output current: 700 mA
- Input voltage: 230VAC
- Maximum input current: 100 mA
- Maximum power: 11W
- Current limitation: 750 mA
- Overload protection
- Short circuit protection
- Overvoltage protection
- Class II protection (double insulation)
- MTBF 30,000 hours
- Operating temperature: 0 .... 40 degrees C
- Storage temperature: -20 .... 85 degrees C
- Cable length: 1.5m
- Dimensions: 77x30x82mm
- Weight: 140g
